List of verified meters
The following list contains M-Bus meters which had been tested and are fully functional with our
The Ethernet converters in the Smart M-Bus application mode can only process standard M-Bus messages without specific manufacturer defined data formats. Manufacturer specific data can be read only by a direct M-Bus communication with a post processing of the M-Bus response in an upper level of the communication system.
The Smart M-Bus application mode stores responses from the basic data request REQ_UD2.
The compatibility of meters with the M-Bus to RS485 and RS232 converters is not affected and is completely guaranteed. All converters fully comply with the M-Bus specification.
Electricity meters
EATON EME3P125Direct connected three phase electricity meter 3x230V/400V with current measurement up to 125A compliant with EU MID (Measuring Instruments Directive). |
|||||||||
| |||||||||
HTML export / meter table
|
EATON KWZ44B1-MDirect connected three phase electricity meter 3x230V/400V with current measurement up to 65A compliant with EU MID (Measuring Instruments Directive). |
|||||||
| |||||||
HTML export / meter table
|
Electricity meters inepro
|
|||||||||
| |||||||||
HTML export / meter table
|
inepro PRO370Three phase electricity meter 3x230V/400V with current measurement up to 65A. MID (Measuring Instruments Directive) approved meter. |
|||||||
| |||||||
HTML export / meter table
|
SCHRACK MGDIZ380-ZDirect connected three phase electricity meter 3x230V/400V with current measurement up to 80A compliant with EU MID (Measuring Instruments Directive). |
|||||||
| |||||||
HTML export / meter table
|
Crompton Instruments / TE Connectivity energy meters with DRM-M add-on moduleThe DRM-M is an optional infra-red communication system for M-Bus by TE Connectivity. It is an add-on module that enables meter readout via M-Bus communication with TE's MID electricity meters.The module is available for the following TE product lines: - Energy Meter Single-phase, Direct Connection - Energy Meter Three-phase, CT Operated - Energy Meter Three-phase, Direct Connection Not all meters from these lines require this module for M-Bus communication and the verified compatibility currently applies only to communication using the add-on module. |
|||||||
| |||||||
HTML export / meter table
|
Heat meters
Itron CF Echo IIModular ultrasonic heat meter. Compatibility applies only to meters equipped with the M-Bus communication plug-in board. |
|||||||||
| |||||||||
HTML export / meter table
|
LandisGyr 2WR5Heat meter with an ultrasonic flow meter. |
|||||||
| |||||||
HTML export / meter table
|
MULTICAL 66Heat meter. Can be connected to flow meters. Additional connection for electricity or water meters. |
|||||||
| |||||||
HTML export / meter table
|
MULTICAL 602Modular heat meter with flowmeter.The verified compatibility was tested only on a MULTICAL 602 meter with Wireless M-Bus module with 2 pulse inputs. |
|||||||||
| |||||||||
HTML export / meter table
|
MULTICAL 603Modular heat meter with flowmeter.Latest heat meter with an option to connect an ultrasound flow meter and automatic detection of it. Wide selection of communication modules and their configurations. |
|||||||
| |||||||
HTML export / meter table
Different configuration of the M-Bus module
|
SensoStar 2UHeat meter with an ultrasonic flow meter. |
|||||||||
| |||||||||
HTML export / meter table
|
SensoStar U (S3)Heat meter with an ultrasonic flow meter. |
|||||||
| |||||||
HTML export / meter table
|
SHARKY 775Heat meter with an ultrasonic flow meter. |
|||||||
| |||||||
HTML export / meter table
|
Supercal 531Multi-functional integrator unit suitable for the measurement of heating or cooling flow and for the combined heating/cooling measurement. |
|||||||
| |||||||
HTML export / meter table
|
Water meters
Itron water meters with the Itron Cyble M-Bus communications moduleM-Bus communication interface module for Itron water meters. Can be fitted to the entire Itron water meter product range: Flodis, |
|||||||
| |||||||
HTML export / meter table
|
Sensus water meters with M-Bus communication module Residia ver.2.2M-Bus communication interface module for Sensus water meters used in ResidiaJet™ water meters. |
|||||||
| |||||||
HTML export / meter table
|
Water meters with M-Bus communication module SIEMENS WFZ31M-Bus communication interface module for water meters. |
|||||||
| |||||||
HTML export / meter table
Simplified mode
|
WEHRLE MODULARIS water meters with M-Bus module |
|||||||||
| |||||||||
HTML export / meter table
|
Other (S0/M-bus converters etc.)
M-Count 2CM-Bus pulse adapter with logging for acquisition and handling of pulses from one or two consumption meters with pulse output. |
|||||||||
| |||||||||
HTML export / meter table
|
PadPuls M1M-Bus pulse adapter for acquisition and handling of pulses from a single consumption meter with pulse output. |
|||||||||
| |||||||||
HTML export / meter table
|
Siemens AEW21.2M-Bus pulse adapter for acquisition and handling of pulses from one or two consumption meters with pulse output. |
|||||||
| |||||||
HTML export / meter table
|
Siemens AEW310M-Bus pulse adapter for acquisition and handling of pulses from one or two consumption meters with pulse output. |
|||||||
| |||||||
HTML export / meter table
|
